Introduction

In the previous article, we introduced the basics of using Terraform to automate Auth0 configuration. In this article, we’ll build a workflow that more closely resembles an enterprise deployment.

Our goals are to:

  • Create Auth0 OIDC clients using Terraform.
  • Store Terraform state in an S3-compatible backend (MinIO).
  • Store generated Auth0 client credentials securely in HashiCorp Vault.
  • Run everything locally while following patterns that can later be migrated to production with minimal changes.

High-Level Architecture

                GitHub Actions (Production)
                        │
        GitHub Secrets / CI Variables
                        │
                        ▼
                  Terraform Apply
                 /                 \
        Auth0 Provider        Vault Provider
               │                    ▲
               ▼                    │
        Create OIDC Clients         │
               │                    │
               └──── Store Client Credentials ───► Vault

          Terraform State ─────────► MinIO (S3 Backend)

Sequence Diagram

Sequence Diagram

Why MinIO?

MinIO provides an S3-compatible object store that lets us simulate an AWS S3 backend locally. This enables us to practice using a remote Terraform backend without requiring an AWS account.

Why HashiCorp Vault?

Applications should never embed secrets inside source code or configuration files.

Instead, Terraform creates the Auth0 clients, retrieves the generated client secrets, and stores them securely in Vault. Applications can later retrieve those secrets during startup.

Project Structure

terraform-auth0-vault/
├── auth0.tf
├── vault.tf
├── providers.tf
├── variables.tf
├── outputs.tf
├── backend.tf
├── dev.tfvars
├── docker-compose.yml
├── .gitignore
└── README.md

Implementation Dependencies

  1. Auth0 Machine-to-Machine application with Management API permissions.
  2. Docker Desktop.
  3. Terraform.
  4. HashiCorp Vault.
  5. Vault CLI.
  6. MinIO.

Auth0 Machine-to-Machine application with Management API permissions.

The Getting Started with Auth0 Automation Using Terraform blog, refrenced in the introductory session of this blog have details on creating Machine-to-Machine application with Management API permissions. So I am not repeating the same in this blog. Make sure to follow the Principle of Least Privilege by assigning only the permissions required.

Docker Compose

Use the docker-compose.yml shown below to start Vault and MinIO.

version: "3.9"

services:

  vault:
    image: hashicorp/vault:latest
    container_name: vault
    restart: unless-stopped

    ports:
      - "8200:8200"

    cap_add:
      - IPC_LOCK

    environment:
      VAULT_DEV_ROOT_TOKEN_ID: myroot
      VAULT_DEV_LISTEN_ADDRESS: "0.0.0.0:8200"

    command: vault server -dev

    volumes:
      - vault-data:/vault/data

  minio:
    image: minio/minio
    container_name: minio
    restart: unless-stopped

    command: server /data --console-address ":9001"

    ports:
      - "9000:9000"
      - "9001:9001"

    environment:
      MINIO_ROOT_USER: admin
      MINIO_ROOT_PASSWORD: password123

    volumes:
      - ./minio-data:/data

volumes:
  vault-data:

In production environments do not hard code the password like above.

Start the containers:

docker compose up -d
docker ps

Providers

providers.tf

provider "auth0" {
  domain        = var.auth0_domain
  client_id     = var.auth0_client_id
  client_secret = var.auth0_client_secret
}

provider "vault" {
  address = var.vault_addr
  token   = var.vault_token
}

variables.tf

variable "auth0_domain" {}

variable "auth0_client_id" {}

variable "auth0_client_secret" {
  sensitive = true
}

variable "vault_addr" {
  type = string
}

variable "vault_token" {
  type      = string
  sensitive = true
}

dev.tfvars

Do not commit this file to Git.

auth0_domain        = "dev-xxxx.us.auth0.com"
auth0_client_id     = "xxxxxxxxxxxxxxxx"
auth0_client_secret = "yyyyyyyyyyyyyyyy"

vault_addr  = "http://127.0.0.1:8200"
vault_token = "myroot"

Add the following to .gitignore:

dev.tfvars
terraform.tfvars
*.auto.tfvars
terraform.tfstate*

Auth0 Resources

Terraform creates two OIDC applications:

  • Order Service
  • Payment Service

auth0.tf

resource "auth0_client" "order_service" {

  name            = "Order Service"

  description     = "OrderService client created through Terraform"

  app_type        = "regular_web"

  callbacks       = [

    "http://localhost:9090/login/oauth2/code/auth0"
  ]

  oidc_conformant = true

  jwt_configuration {

    alg = "RS256"

  }

}


resource "auth0_client" "payment_service" {

  name            = "Payment Service"

  description     = "PaymentService client created through Terraform"

  app_type        = "regular_web"

  callbacks       = [
    "http://localhost:3000/callback"
  ]

  oidc_conformant = true

  jwt_configuration {

    alg = "RS256"

  }

}

Retrieving Client Secrets

Terraform first creates the Auth0 clients.

Next, it uses the Auth0 data source to retrieve the generated client secrets.

Finally, it stores the client ID and client secret in Vault.

vault.tf

data "auth0_client" "order_service" {
  client_id = auth0_client.order_service.client_id
}

data "auth0_client" "payment_service" {
  client_id = auth0_client.payment_service.client_id
}

resource "vault_kv_secret_v2" "order_secret" {

  mount = "secret"

  name = "auth0/order-service"

  data_json = jsonencode({

      client_id     = auth0_client.order_service.client_id

      client_secret = data.auth0_client.order_service.client_secret

  })

}

resource "vault_kv_secret_v2" "payment_secret" {

  mount = "secret"

  name = "auth0/payment-service"

  data_json = jsonencode({

      client_id     = auth0_client.payment_service.client_id

      client_secret = data.auth0_client.payment_service.client_secret

  })

}

Outputs

Define outputs to display the generated client IDs and Vault paths.

outputs.tf

output "order_service_client_id" {
  description = "OIDC Client ID for Order Service"
  value       = auth0_client.order_service.client_id
}

output "payment_service_client_id" {
  description = "OIDC Client ID for Payment Service"
  value       = auth0_client.payment_service.client_id
}

output "order_service_vault_path" {
  description = "Vault path for Order Service credentials"
  value       = "secret/auth0/order-service"
}

output "payment_service_vault_path" {
  description = "Vault path for Payment Service credentials"
  value       = "secret/auth0/payment-service"
}

Run:

terraform init
terraform plan -var-file=dev.tfvars
terraform apply -var-file=dev.tfvars

Verify Vault:

vault kv list secret/auth0
vault kv get secret/auth0/order-service
vault kv get secret/auth0/payment-service

Remote Backend using MinIO

Terraform maintains a terraform.tfstate file that represents the current infrastructure state.

In production this file should not remain on a developer workstation. Instead, it should be stored in a remote backend such as AWS S3.

For local development we use MinIO, an S3-compatible object store.

Create a bucket named terraform-state and configure backend.tf

backend.tf

terraform {

  backend "s3" {

    bucket = "terraform-state"
    key    = "auth0-demo/terraform.tfstate"
    region = "us-east-1"

    endpoints = {
      s3 = "http://localhost:9000"
    }

    access_key = "admin"
    secret_key = "password123"

    skip_credentials_validation = true
    skip_metadata_api_check     = true
    skip_region_validation      = true
    skip_requesting_account_id  = true
    skip_s3_checksum            = true

    use_path_style = true
  }
}

Re-run:

terraform init

Terraform will migrate the state to MinIO.

Production Considerations

In production:

  • Store Auth0 Management API credentials in GitHub Secrets or another secure CI/CD secret store.
  • Store Terraform state in AWS S3 (or equivalent).
  • Use managed HashiCorp Vault or another enterprise secret manager.
  • Authenticate GitHub Actions to Vault using OIDC/JWT instead of long-lived tokens.
  • Keep separate environments for Development, Staging and Production.

Conclusion

This tutorial demonstrated an enterprise-style infrastructure provisioning workflow using Auth0, Terraform, Vault and MinIO while running entirely on a local machine.

In a follow-up article, we will build on this foundation by integrating Kubernetes with HashiCorp Vault so that applications can securely retrieve Auth0 client credentials at runtime without embedding secrets in configuration files.
